The Wheeltop RDDP780-GS oversized pulley cage is an upgrade for EDS TX rear derailleurs. It combines a 93 mm carbon-fibre cage with 12T and 18T oversized pulley wheels, ceramic bearings and a reflective finish.
The larger pulley wheels reduce the amount of articulation required as the chain passes through the derailleur, while the ceramic bearings help minimise pulley resistance. The system retains a 36T derailleur capacity and supports cassettes with a maximum sprocket between 30T and 36T.
Key features
- Compatible with Wheeltop EDS TX rear derailleurs
- 93 mm carbon-fibre cage
- 12T upper guide pulley
- 18T lower tension pulley
- Ceramic pulley bearings
- Reflective finish
- 36T total derailleur capacity
- Compatible with maximum sprocket sizes from 30T to 36T
- Average weight of 104 ± 5 g
Specifications
| Model | RDDP780-GS |
|---|---|
| Cage length | 93 mm |
| Cage material | Carbon fibre |
| Upper guide pulley | 12T |
| Lower tension pulley | 18T |
| Pulley bearings | Ceramic |
| Finish | Reflective |
| Smallest cassette sprocket | 10T to 11T |
| Maximum cassette sprocket | 30T to 36T |
| Total derailleur capacity | 36T |
| Average weight | 104 ± 5 g |
| Compatibility | TX-RA7000, TX-RA7100, TX-TA6000 and TX-RA7800 |
